Raymarine/Aimar PM111LH-W 2000W D/T In Hull/Pocket/Keel Mount Low-High Wide Beam Transducer

SKU: A80326

$6,550.00 $6,999.00

Description

The Airmar PM111LH-W is a professional-grade dual-band CHIRP transducer engineered for serious fishing and commercial applications. Its exclusive wide-beam High CHIRP design maintains a constant 25° beam angle across the entire high-frequency spectrum, delivering superior shallow-water coverage without sacrificing resolution.

With 2 kW of low-frequency power and 137 kHz of total bandwidth from a single transducer, the PM111LH-W covers the popular 50, 68, and 200 kHz fishing frequencies — and everything in between. Designed for custom in-hull, pocket, or keel mounting, it suits vessels 12 m (40') and above with any deadrise angle.

Key Features

Depth and fast-response water temperature sensing
Low CHIRP (38–75 kHz): 2 kW power, 19°×10° to 10°×5° beam, max depth 1,829 m (6,000')
High Wide CHIRP (150–250 kHz): 1 kW power, constant 25° beam, max depth 152 m (500')
137 kHz total bandwidth from a single transducer
Covers 50, 68, and 200 kHz fishing frequencies plus full bandwidth range
Curved-edge design for wet-box installation
SEALCAST™ seamless urethane housing for long-term underwater durability
Patented Xducer ID® technology
Also available as a thru-hull external mount (R109LHW)

Specifications

Brand: Airmar Technology
Mounting: Tank, cavity, pocket/keel (custom installation)
Connector: Bare wire
Cable length: 15 m (49')
Weight: 13.6 kg (30 lb)
Acoustic window: Epoxy/urethane
Max vessel LOA: 12 m (40') and above
Country of origin: USA
