Mente Marine Dual Helm 520/ACSA Automatic Trim Tab Control with 12m Harness

SKU: 520/ACSA

$1,929.00 $2,150.00

Description

Mente Marine 520/ACSA Automatic Trim Tab Control – Dual Helm with 12m Harness

The Mente Marine ACSA is an advanced automatic trim tab controller offering manual control, automatic trim control, position indicator lights, and auto tab retract — all from a single keypad on the dashboard. No relay modules or additional harnesses required. Compatible with virtually all conventional hydraulic and electric trim tab systems.

ACSA Model – Suits All Boats

Ideal when connecting to trim tabs via the engine room
Suits planing and semi-displacement hulls
Compatible with shaft drives, sterndrives, IPS, and outboards
Optional flybridge control panel available
Typical boat length: 25 to 50 feet

Key Features

Manual and automatic trim tab control
Indicator lights showing tab position — no senders required (can be retrofitted with boat in the water)
Auto tab retract function
Controls both roll and pitch
Works with hydraulic trim tabs (Bennett, Insta Trim) and electric trim tabs (Bennett, Lenco, Lectrotab)
Does not work with interceptor-style systems (e.g. ZipWake)
Intuitive interface with adjustable auto-response sensitivity

Download the ACSA User Guide (PDF)
