Harrold Marine

Quick 200A Hydraulic Magnetic Circuit Breaker (DC Windlass Protection)

SKU: FD1020000000A00

$819.00

Description

The Quick FD10200 is a 200A hydraulic magnetic circuit breaker designed for DC marine applications, providing essential overcurrent protection for windlasses and other high-draw electrical equipment. Its slow-burn mechanism trips reliably under short-circuit or prolonged overload conditions, interrupting the circuit before damage occurs. Manually resettable once the fault is cleared.

Key Features

200A current rating — suitable for high-draw windlass installations
Slow-burn hydraulic magnetic trip mechanism
Protects against short circuits and prolonged overloads
Manual reset once fault condition is resolved
Rated for DC systems up to 80V
Operates reliably across extreme temperatures: -40°C to +85°C
Compact and robust design for marine and industrial environments

Specifications

Model: FD1020000000A00
Current Rating: 200A
Voltage: Up to 80V DC
Type: Slow-burn hydraulic magnetic circuit breaker
Reset: Manual
Operating Temperature: -40°C to +85°C
Application: Windlass protection, marine and industrial DC systems
