Quick Horizontal Windlass (PTG700 Strap 250W 12V No Bow Sprit)

SKU: FSPT0700G000A00

$4,099.00

Description

The Quick PTG700 is a compact horizontal capstan winch designed for pontoons, small boats, and tenders where deck space is limited. Available in 12V DC, it delivers 250W of pulling power with a working load of 80 kg and a maximum pull load of 600 kg. Built from AISI 316 stainless steel and anodised aluminium for long-term marine durability.

DOES NOT INCLUDE SWITCH OR CIRCUIT BREAKER

Key Features

Available in 12V DC — specify voltage when ordering
250W motor with 80 kg working load / 600 kg maximum pull load
Strap roller system — retrieves 48mm wide × 7.5m strap
Line speed: 18.1 m/min at working load
AISI 316 stainless steel and anodised aluminium construction
Suitable for anchor retrieval, tender lifting, or fishing capstan use
Installs above or below deck
CE approved

Specifications

Model: FSPT0700G000A00
Voltage: 12V DC
Power: 250W
Working Load: 80 kg (176 lb)
Maximum Load: 220 kg (485 lb)
Maximum Pull Load: 600 kg (1,323 lb)
Line Speed: 20.8 m/min max / 18.1 m/min at working load
Current Draw: 23A at 80 kg (12V)
Fuse: 20A protection circuit breaker
Dimensions: H 173mm × W 220mm × D 294mm
Mounting Holes: 4 × 9mm
Contents: Capstan, contactor unit, bolts and screws, drill template, user manual

SKU FSPT0700G000A00 is the 12V variant. Contact us for 24V pricing and availability.
