Quick Totem TM 600G Horizontal Capstan 500W 12V for Tender

SKU: FSTM0600G000A00

$4,399.00

Description

The Quick Totem TM 600G (FSTM0600G000A00) is a compact 500W, 12V horizontal capstan designed for small boat tenders. Built from AISI 316 stainless steel with an anodised aluminium epicyclical gearbox (over 40% more efficient than traditional gearboxes) and an IP66 watertight motor. Includes a roller for strap handling. CE approved. Genuine Quick Italian manufacture.

Performance Specifications

Motor Power: 500W
Voltage: 12V DC
Maximum Pull: 620kg (1,367 lb)
Maximum Working Load: 200kg (441 lb)
Working Load: 65kg (143 lb)
Current Draw @ Working Load: 40A
Recommended Fuse: 50A circuit breaker
Maximum Chain Speed: 15.4 m/min (50.5 ft/min)
Chain Speed @ Working Load: 11.9 m/min (39 ft/min)

Dimensions

Height: 160mm (6-5/16")
Width (overall): 332mm (13-3/32") — Drum side: 129mm, Non-drum side: 203mm
Depth: 171mm (6-3/4")
Drum Diameter: 80mm (3-5/32")
Deck Thickness: 20–40mm
Mounting Plate: 160mm × 125mm | Hole spacing: 120mm × 85mm
Motor Cable: 16mm² (AWG5)

Key Features

Roller for strap handling
AISI 316 stainless steel base
IP66 watertight motor
Anodised aluminium epicyclical gearbox — 40%+ efficiency gain
CE approved

Product Details

Series: Quick Totem G (TMG)
Includes: Capstan, handle, contactor unit, bolts and screws, drill template, user manual
Classification: Genuine Quick product
Origin: Genuine Quick Italian manufacture
