Vetus MPA22 Marine Aluminium Engine Panel — 218 × 157mm

SKU: MPA22KBS2

$1,129.00 $1,160.78

Description

Vetus MPA22 Marine Aluminium Engine Panel — 218 × 157mm

A premium helm station engine panel crafted from marine-grade anodised aluminium, the Vetus MPA22 brings a stylish and functional upgrade to any dashboard. Subtle curves and contours give the panel a modern, elegant look, while the included gauges and warning systems provide everything needed for reliable engine monitoring.

The MPA22 includes an ignition key, tachometer, hour meter, voltmeter, and LED + acoustic warning signals. For additional gauges, the optional MPA1XB extension panel accommodates two extra instruments (sold separately).

Electrical connections are backwards compatible with older Vetus panels, making it a straightforward upgrade.

Key Features

Marine-grade anodised aluminium construction
Includes: ignition key, tachometer, hour meter, voltmeter, LED & acoustic warning signals
IP64 splash-proof (front face, when correctly installed)
Available with black or white gauges
Compatible with 12V and 24V systems
Expandable with MPA1XB extension panel (2 extra gauges)
Backwards compatible with older Vetus panel wiring
Supplied with gaskets and mounting screws

Specifications

Panel Dimensions: 218 × 157mm
Built-in Depth: 120mm
Voltage: 12V or 24V DC
RPM Range: 0–4,000 RPM (tachometer)
IP Rating: IP64 (front face)
Finish: Black weatherproof coating

Custom colours available for orders of 100+ panels.
